9460M Remote Area Light

made in usa

Colours

OVERVIEW

“M” for mobility, the 9460M is built with a set of XL wheels providing easy transport over rough terrain. The all new and extremely powerful 9460M Remote Area Lighting System (RALS) provides convenient and ecologically responsible alternatives to wasteful generator powered lights. Engineered with the Intelligent Control System which calculates and displays current battery life. Additionally, it allows the user to regulate the intensity of the light, choose the desired run time or select from three pre-set power levels. Built with versatility in mind, the 9460M RALS features two telescopic masts (each extends to nearly 6 feet) and two 360° articulating light heads. The system's next-generation LEDs combine to radiate up to 12,000 lumens (6,000 per light head). For extended applications, the 9460M can run continuously on wall power. The ability to leave on charge allows you to always be prepared. A 12 volt power port including a dual USB adapter provides power for many peripheral devices. Built self-contained in a tough-as-nails Pelican case, the 9460M is compact and includes the multi-terrain trolley with a retractable pull handle and stainless steel ball-bearing 1.5 inch polyurethane wheels.
CAUTION: The Pelican Products RALS models 9460 and 9470 contain sealed lead acid batteries that can generate hydrogen gas when charging. It is imperative that these products are charged, as instructed, with the case lid open to allow any gases to escape as charging with the lid closed poses a significant hazard. Failure to abide by this instruction could result in injury and/or damage to property. Please refer to the warnings provided in the instructions for the unit and on a decal affixed to the inside of the case adjacent to the cavity where the charger unit is packed.

NEW UPGRADED SPECS

  • Dual telescoping LED light heads
  • Multi-terrain trolley w/ 1.5” wheels
  • Housed in a Pelican™ Protector Case™ housing
  • Dual USB power adapter
  • Silent operation
  • Cool operating temperatures
  • No exhaust
  • Upright and lie flat pole brackets
  • Full time battery level indication with low level flashing indicator
  • RoHS and CE Compliant
pelican 9460m mobility remote rals light
pelican 9460m 9490 remote area lightpelican 9490 9460m firefighter rals light

ACCESSORIES

REPLACEMENT PARTS


Part number Description Generation
009463-2067-000 THREAD FORMING SCRW ¯5 x 18MM,T25 SS,A2 3
009463-6239-000 POLE BRACKET LOW PROFILE,9460C/70C 3
009463-6240-000 POLE BRACKET TALL,RH,9460C 3
009463-2323-000 CABLE TIE MNT,SGABM25-AV-C300,9460B/70B 3
009465-5320-000 TOP INSERT,21 x 11 x 1/2",9460C 3
009463-6243-000 HEAD TRAY BRACKET LEFT, 9460C 3
009463-4235-000 FOAM BLOCK C, HEAD TRAY, 9460C 3
009463-4234-000 FOAM BLOCK B, HEAD TRAY, 9460C 3
009463-4233-000 FOAM BLOCK A, HEAD TRAY, 9460C 3
9465-531-002 CARTON,9460C,PLAIN-PACKAGING BOX 3
009463-2033-000 SCREW, M5 X 16MM SOCKET BUTTON A2 3
009463-2063-000 THREAD FORMING SCRW ¯3 x 16MM-T10 SS,A2 3
009463-2326-000 FIBRE WASHER M5 - BLACK (Keystone #3171) 3
009463-6242-000 POLE BRACKET TALL,LH,9460C 3
009463-2270-000 THREAD FORMING SCREW FOR PLASTIC 5x10 PT 3
009463-2163-000 SCREW, M4 x 8mm, MACHINE, POZI PAN A2 3
009466-6230-110 COMPLETE LIGHT HEAD ASSY,9460C/9470C,BLK 3
009463-2330-000 PROTECTION VENT 21.5 x 12.5, 9460C/9470C 3
009463-3538-000 USB TWIN ADAPTER,9460C/9470C 3
009465-5340-000 TOP & BTTM PAD-22-1/8 x 13-7/8 x 1,9460C 3
009465-5330-000 END CAP PAD - 28 x 11 x 1 x 1",9460C 3
009433-3537-000 CIGARETTE SOCKET 3
009466-3143-000 POWER SUPPLY ASSY,9460C,PELICAN 3
009463-4236-000 FOAM COVER BATTERY BRACKET,9460C 3
009466-3440-000 SOURIAU ADAPTOR ASSY,CHARGE SOCKET 3
009466-3372-000 MAIN WIRING LOOM ASSY,9460C 3
009466-2150-000 SOURIAU ADAPTOR ASY,LIGHT HEAD,9460C/70C 3
009463-5138-001 SERIAL NO.LABEL,PELICAN,9460C,US 3
9463-311-001 INSTR MANUAL,PELICAN,9460C,US 3
009466-3348-001 BATTERY LOOM,9460C 3
009463-4232-000 LID FOAM,9460C 3
001516-1010-240 CASE-ASY,DRILLED-TOOLING,NL/NF,9460C,YW 3
009463-4387-000 BATTERY FOAM,9460(B) 3
009463-4323-000 BATTERY PACKING BLOCK,9460 3
009463-2112-000 LID POLE BRACKET,9460C 3
009463-2113-000 BATTERY BRACKET,9460B 3
009463-4140-001 VAC. FORMED LAMP HEAD TRAY,9460C 3
009463-3142-000 VRLA BATTRY 12V 39AH 3
009463-6241-000 HEAD TRAY BRACKET RIGHT, 9460C 3
009466-3359-000 CHARGER MODULE ASSY,9460C 3
009463-3354-000 ICU BEZEL,9460C/9470C 3
009463-5561-001 CHARGER PRECAUTIONS LABEL 3
009463-2531-000 SNAP BUSH,HEYCO SB812-9,BLACK 3
009473-2237-000 FIBRE WASHER M6 - BLACK (Keystone #3373) 3
009463-2334-000 M6 WASHER A2 FORM A 3
009473-2236-000 M6 x 20mm SOCKET BUTTON HD SCREW A2 3
009443-2480-000 CABLE TIE,200MM X 2.5MM,NYLON BLACK 3
009463-2318-000 'S' CLIP 3
009463-2228-000 POLE CLIP - 81125BP 3
009466-3351-001 INTELLIGENT CNTRL MODULE,9460C/9470C 3
009466-3142-000 Battery, 9460/70, Gen I/II/RS 2
009466-2111-000 POLE CARRIER Kit, 9460B/RS,70B/RS (set of 2) 2
009463-3348-000 Green rt angle hd plug Kit, 9460B/RS/70B/RS 2
1516-931-110 Dolly 1510, 3 piece assembly 2
009466-6240-000 POLE ASSEMBLY,COMPLETE,9460/9470 2
009466-3556-245 LIGHT HEAD,9460B-RS/9470B-RS,YELLOW 2
009466-3556-110 LIGHT HEAD,9460B-RS/9470B-RS,BLACK 2
009463-3290-000 MAIN POWER LEAD,UK MC-5224,PELI 2
009463-3289-000 MAIN POWER LEAD,EU MC-3226,PELI 2
009463-3288-000 MAIN POWER LEAD,USA MC-1122,PELICAN 2
009463-3341-000 MAIN POWER LEAD,AUS MC-9020,PELICAN 2
009466-5138-000 LABEL SET PELICAN Kit, 9460B 2
009466-2141-000 METAL WORK Kit, 9460B/RS 2
009466-3322-000 WIRING Kit, 9460B/RS 2
009466-3355-000 IC MODULE ASSY, 9460B/9470B 2
009466-6240-000 POLE ASSEMBLY,COMPLETE,9460/9470 2
009466-6561-110E CASE M/C ASSY,9460B, BLACK - Peli 2
009466-6561-245E CASE M/C ASSY,9460B,YELLOW - Peli 2
1513-101-110 CASE M/C ASSY,9460B, BLACK - Pelican 2
1513-101-240 CASE M/C ASSY,9460B,YELLOW - Pelican 2
009466-4142-000 FOAM & TRAY Kit, 9460B/RS 2
009466-3555-000 CHARGER ASSEMBLY, 9460B/RS (leads not inc) 2
009466-2069-000 FIXINGS Kit, 9460B/RS 2
009466-3049-000 PCB/SW ASSY Kit, 9460/70 Gen I, PELICAN 1
009466-6560-110E CASE M/C ASSY,9460 Gen I,BLACK 1
009466-2110-000 POLE CARRIER + FIX Kit, 9460/70 Gen I 1
009466-3142-000 Battery, 9460/70, Gen I/II/RS 1
009436-6203-110 HEAD PLASTCS+CABLE Kit, 9430A/60A/70A 1
009433-3036-000 Blue rt angle hd plug Kit, 9430A,SL,IR,60A,70A 1
009466-3553-000 CHARGER ASSY, 9460 Gen I (leads not inc) 1
009466-4107-000 FOAM + TRAY Kit, 9460 Gen I 1
009463-3341-000 MAIN POWER LEAD,AUS MC-9020,PELICAN 1
009466-3347-000 WIRING Kit, 9460 Gen I 1
009466-2273-000 METALWORK Kit, 9460 Gen I 1
009466-5133-000 LABEL SET Kit, 9460 Gen I, PELICAN 1
009466-6560-245E CASE M/C ASSY,9460 Gen I, YELLOW 1
009466-2068-000 FIXINGS Kit,9460 Gen I 1
009466-3554-110 LIGHT HEAD, 9460/70 Gen I,BLACK 1
009466-3554-245 LIGHT HEAD, 9460/70 Gen I,YELLOW 1
009433-9048-000 Switch Key Pad, 9430 Series/9460/70 Gen 1 1
1516-931-110 Dolly 1510, 3 piece assembly 1
009433-3104-000 Blue charger straight plug Kit 1
009463-3288-000 MAIN POWER LEAD,USA MC-1122,PELICAN 1
009463-3289-000 MAIN POWER LEAD,EU MC-3226,PELI 1
009463-3290-000 MAIN POWER LEAD,UK MC-5224,PELI 1
009466-6240-000 POLE ASSEMBLY,COMPLETE,9460/9470 1
DIMENSIONS
Head (L×W×D)
8.25 x 5.75 x 2.25 in
(21 x 14.6 x 5.7 cm)
Closed (L×W×D)
23.25 x 14.00 x 9.25 in
(59.1 x 35.6 x 23.5 cm)

MEASUREMENTS
Light Head Height (max)
79.50" (201.9 cm)
Cord Length
13.78" (35 cm)

WEIGHTS
Weight
64.00 lbs (29 kg)

MATERIALS
Body Material
Polypropylene
Head Material
Aluminum
Mast Material
Aluminum
Lens Material
Polycarbonate (PC)
