OVERVIEW
Pelican™ Protector Case™
Sensitive equipment needs protection, and since 1976 the answer has been the Pelican™ Protector Case. These cases are designed rugged, and travel the harshest environments on earth. Against the extreme cold of the arctic or the heat of battle, Pelican cases have survived.
Made in the USA, these tough cases are designed with an automatic purge valve, that equalizes air pressure, a watertight silicone O-ring lid, over-molded rubber handles and stainless steel hardware.
Configuration:
1610 Protector Case
The With TrekPak Divider System (1610TP) configuration includes:
- 1610 Protector Case
- TrekPak Divider System
- Two perimeter pieces
- Two 9 inch dividers
- Two 23 inch dividers
- Cutting Tool
- 30 pins with 30 red pull tabs
1610 Protector Case
The With Padded Dividers (1614) configuration includes:
- 1610 Protector Case
- Padded Dividers
1610 Protector Case
The No Foam (1610NF) configuration includes:
- 1610 Protector Case
1610 Protector Case
The With Foam (1610WF) configuration includes:
- 1610 Protector Case
- Foam Layers
- Foam Layer 1 (Lid) - 2.00" (5.1 cm) Convolute
- Foam Layer 2 (Base) - 2.38" (6 cm) Pick N Pluck (.50" x .50" squares)
- Foam Layer 3 (Base) - 2.38" (6 cm) Pick N Pluck (.50" x .50" squares)
- Foam Layer 4 (Base) - 2.38" (6 cm) Pick N Pluck (.50" x .50" squares)
- Foam Layer 5 (Base) - 1.50" (3.8 cm) Solid
- Watertight, crushproof, and dustproof
- Strong polyurethane wheels with stainless steel bearings
- 3 level Pick N Pluck™ with convoluted lid foam
- Open cell core with solid wall design - strong, light weight
- Retractable extension trolley handle
- Fold down handles
- Easy open double-throw latches
- Automatic pressure equalization valve - balances interior pressure, keeps water out
- Stainless steel hardware and padlock protectors
- O-ring seal
- Personalized nameplate service available
ACCESSORIES
YOU MAY ALSO LIKE
SPECS
DIMENSIONS
Interior (L×W×D)
21.78 x 16.69 x 10.62 in
(55.3 x 42.4 x 27 cm)
(55.3 x 42.4 x 27 cm)
Exterior (L×W×D)
24.83 x 19.69 x 11.88 in
(63.1 x 50 x 30.2 cm)
(63.1 x 50 x 30.2 cm)
MEASUREMENTS
Lid Depth
2.05" (5.2 cm)
Bottom Depth
8.57" (21.8 cm)
Total Depth
10.62" (27 cm)
Int Volume
2.23 ft³ (0.063 m³)
Padlock Hole Diameter
0.31" (0.8 cm)
WEIGHTS
Weight With Foam
22.3 lbs (10.1 kg)
Weight Empty
19.5 lbs (8.8 kg)
Buoyancy
119.93 lbs (54.4 kg)
MATERIALS
Body Material
Polypropylene
Latch Material
ABS
O-Ring Material
Polymer
Pins Material
Stainless Steel
Foam Material
1.3 lb Polyurethane
Purge Body Material
ABS
Purge Vent Material
3 Micron Hydrophobic Non-Woven
TEMPERATURES
Minimum Temperature
-40° F (-40 ° C)
Maximum Temperature
190° F (88 ° C)
OTHERS
Wheels
2
Extendable Handle
yes
APPROVALS
Certifications
IP67 / Def Stan 81-41
