OVERVIEW
Pelican™ Protector Case™
Sensitive equipment needs protection, and since 1976 the answer has been the Pelican™ Protector Case. These cases are designed rugged, and travel the harshest environments on earth. Against the extreme cold of the arctic or the heat of battle, Pelican cases have survived.
Made in the USA, these tough cases are designed with an automatic purge valve, that equalizes air pressure, a watertight silicone O-ring lid, over-molded rubber handles and stainless steel hardware.
Configurations:
1520 Protector Case
The With Padded Dividers (1524) configuration includes:
- 1520 Protector Case
- Padded Dividers
1520 Protector Case
The No Foam (1520NF) configuration includes:
- 1520 Protector Case
1520 Protector Case
The With Foam (1520WF) configuration includes:
- 1520 Protector Case
- Foam Layers
- Foam Layer 1 (Lid) - 1.75" (4.4 cm) Convolute
- Foam Layer 2 (Base) - 4.00" (10.2 cm) Pick N Pluck (.50" x .50" squares)
- Foam Layer 3 (Base) - 0.75" (1.9 cm) Solid
- Pick N Pluck™ with convoluted lid foam
- Watertight, crushproof, and dustproof
- Open cell core with solid wall design - strong, light weight
- Comfortable rubber over-molded handle
- Easy open double-throw latches
- Stainless steel hardware and padlock protectors
- Automatic pressure equalization valve - balances interior pressure, keeps water out
- O-ring seal
- Personalized nameplate service available
- Lifetime Guarantee of Excellence
ACCESSORIES
YOU MAY ALSO LIKE
SPECS
DIMENSIONS
Interior (L×W×D)
18.06 x 12.89 x 6.72 in
(45.9 x 32.7 x 17.1 cm)
(45.9 x 32.7 x 17.1 cm)
Exterior (L×W×D)
19.78 x 15.77 x 7.41 in
(50.2 x 40.1 x 18.8 cm)
(50.2 x 40.1 x 18.8 cm)
MEASUREMENTS
Lid Depth
1.79" (4.5 cm)
Bottom Depth
4.93" (12.5 cm)
Total Depth
6.72" (17.1 cm)
Int Volume
0.91 ft³ (0.026 m³)
Padlock Hole Diameter
5/16" (8 mm)
WEIGHTS
Weight With Foam
9.35 lbs (4.2 kg)
Weight Empty
8.29 lbs (3.8 kg)
Buoyancy
63.00 lbs (28.6 kg)
MATERIALS
Body Material
Polypropylene
Latch Material
ABS
O-Ring Material
Polymer
Pins Material
Stainless Steel
Foam Material
1.3 lb Polyurethane
Purge Body Material
ABS
Purge Vent Material
3 Micron Hydrophobic Non-Woven
TEMPERATURES
Minimum Temperature
-40° F (-40 ° C)
Maximum Temperature
210° F (99 ° C)
Approvals
Certifications
IP67 / MIL C-4150J / Def Stan 81-41
