OVERVIEW
Remote Area Lighting Systems from Pelican are the complete lighting solution for first responders, industrial and aerospace applications.
- Up to 4,000 lumens (calculated)
- Up to 28 hrs of run time
- 3 pre-set light output levels
- Built Pelican tough
- Full time battery level indication with low level flashing indicator
- Deployable mast with 340 degree rotation
- Multiple deployment positions
- Convenient shoulder strap
- Quick release / Hot swappable battery design with 12 volt power supply
REPLACEMENT PARTS
| Part number | Description | Generation |
|---|---|---|
| 009483-3054-000 | WIRE,POWER PACK PCB ASSY,9480/90 | |
| 009485-5340-000 | PROTECTIVE INSERT,LIGHT HEAD,9480/9490 | |
| 009486-3047-000 | COMPLETE BATTERY ASSY,9480/90 | |
| 009483-0303-000 | COMPLETE POWER SUPPLY ASSY,9440B/9480/9490 US | |
| 009483-0303-000E | COMPLETE POWER SUPPLY ASSY,9440B/9480/9490 EU | |
| 009483-0304-000 | POWER SUPPLY OUTPUT PLUG-SOURIAU | |
| 009483-2066-000 | PIN,STRAP,9480/90 | |
| 009483-2431-000 | POLE CLIP SPRING,9480/90 | |
| 009483-2434-000 | POLE CLIP,9480/90 | |
| 009483-3044-000 | POWER PACK PCB ASSY,9480/90 | |
| 009483-9441-000 | STRAP,9480/90,PELICAN | |
| 009483-5071-000E | LABEL-LOGO-PELI,9480/90,BATTERY ASSY | |
| 009483-5072-000E | BATTERY LABEL-SERIAL-PELI,9480/90 | |
| 009483-5073-000 | BATTERY LABEL-FUSE RATING,9480/90 | |
| 009483-6042-110 | WIRING COVER PLATE,BLACK,9480/90 | |
| 009483-9441-000E | STRAP,9480/90,PELI | |
| 009486-3048-110 | BATTERY CONTACT PLATE ASSY,9480/90,BK | |
| 009486-6041-000 | BATTERY CLAMP LATCH,9480/90 | |
| 009483-3331-000 | PC LENS,LAMPHEAD,9480/90,LIGHT HEAD ASY | |
| 009436-3047-001 | Battery, 9430A,B,C,IR,SL | |
| 009485-5320-000 | INSERT,CARTON,PACKING BOX,9480 | |
| 009483-3042-000 | BATTERY CASE HALF-DEEP | |
| 009483-3043-000 | OVER-MOULDED BATTERY PACK HANDLE-9480 | |
| 009483-3048-000 | SOURIAU SEAL CAP,9480(UTL10DCG) | |
| 009483-3343-000 | BEZEL,SWITCH ASSY,9480 | |
| 009483-4060-000 | FOAM PACKING BLOCK,9480 | |
| 009483-5070-000 | POWER PACK LABEL-BATTERY INDICATOR,9480 | |
| 009483-5074-000E | BRANDING LABEL-PELI,LIGHT HEAD ASY,9480 | |
| 009483-5075-000E | LABEL,SWITCH MAIN HOUSING ASY,9480,PELI | |
| 009483-5076-000E | DECAL,SERIAL-9480,PELI | |
| 009483-3041-000 | BATTERY CASE HALF-SHALLOW | |
| 009486-3050-000 | FUSE & FUSE HOLDER ASSY,9480 | |
| 009486-3340-000 | SWITCH ASSY,9480 | |
| 009483-6040-110 | CASE HALVES ASSY,9480,BLACK | |
| 009483-6040-245 | CASE HALVES ASSY,9480,YELLOW | |
| 009486-6240-000 | COMPLETE POLE ASSEMBLY,9480 | |
| 009483-2480-000 | WIRE COVER,LIGHT HEAD ASSY,9480/90 | |
| 009483-3420-000 | 12V LEAD,9480/9490 | |
| 009483-5074-000 | BRANDING LABEL,PELICAN,LIGHT HD ASY,9480 |
YOU MAY ALSO LIKE
SPECS
DIMENSIONS
Head (L×W×D)
21 x 14.6 x 5.7 cm
Closed (L×W×D)
39.4 x 16.5 x 26 cm
MEASUREMENTS
Light Head Height (max)
60.3 cm
WEIGHTS
Weight
12.5 kg
MATERIALS
Body Material
Polypropylene
Head Material
Aluminum
Mast Material
Aluminum
Lens Material
Polycarbonate (PC)
